Thread Standard
2024-12-05
Standard Code
| Description
|
60
| Partial Profile 60° |
55
| Partial Profile 55° |
ISO
| ISO Metric Thread 60° |
UN
| Unified National Thread 60° |
UNJ
| American Unified Aerospace Thread 60° |
MJ
| Metric Aerospace Thread 60° |
W
| British Whitworth Thread 55° |
NPT
| National Pipe Taper 60° |
NPTF
| National Pipe Taper Fuel 60° |
NPS
| National Pipe Straight 60° |
BSPT
| British Standard Pipe Thread 55° |
APIRD
| APl Round Casing & Tubing Thread 60° |
TR
| Metric Trapeze Thread 30° (DIN103) |
ACME
| American Trapeze ACME Thread 29° |
STACME
| American Trapeze Stub ACME Thread 29° |
SAGE
| Metric Buttress Thread 3°/30° (Säge)(DIN513) |
ABUT
| American Buttress Thread 7°/45° |
B.S.BUTTRESS
| British Buttress Thread 7°/45° |
RD
| Round Thread 30° (DIN405) |
RD20400
| Round Thread 30° (DIN20400) |
PG
| Germany Steel Conduit Thread 80° (PG) (DIN40430) |
VAM
| American VAM Thread |
EL
| API-EL Thread |
H90
| Hughes Thread H90 |
